Aspire 225-ES

Solar Energy Storage

Description

data sheetData sheet

The ASPIRE 225 is designed to meet the demand for versatile solar powered lighting in areas where traditional systems are impractical or too costly. This model features a single solar panel and operates with up to four batteries, offering a reliable off-grid solution. Its scalable modular design allows for customisation to specific application needs. Ideal for modern architectural environments, the ASPIRE 225 combines elegance with functional lighting infrastructure.

Technical

Solar Panel 225Wp
Panel Efficiency Rating 22%
Battery Type LiFePO4 25.8V
Battery Capacity 57.6Ah / 1474Wh (2 batteries)
86.4Ah / 2211Wh (3 batteries)
115.2Ah / 2948Wh (4 batteries)
Materials Aluminium/Steel
Finish Brushed/Galvanised
IP Rating IP66 / IP68 Connectors
IK Rating IK08
Operational Temp Range -4°F to 140°F
Certifications CE, ANSI C136.31, ISO9001
Warranty 6 + 10* years
*Warranty period is listed as – Complete Unit + Battery (Pro-rata) – Full warranty details are available upon request
